ATT739

  • image
  • PRODUCT HIGHLIGHT

    – UHF RFID EPC Gen2, ISO / IEC 18000-6C
    – Impinj E310
    – Simple USB interface provides both power and communications
    – High-hardness aluminum outer frame & Tempered Glass Panel
    – Easy installation for any needed space

  • FCC
    FCC
    TELEC
    KC

    • Features & Specifications

    PERFORMANCE
    Processor Cortex Core
    Supported Platforms Windows
    PHYSICAL CHARACTERISTICS
    Dimensions
    (W x L x H)    		 300 x 300 x 20 mm
    Weight 1.6 Kg
    Power USB 5V / 2A
    USB Interface 1 USB Port Type-C
    Host Protocol VCP
    Notification LED Indication, Buzzer
    DATA COLLECTION
    UHF RFID Protocol : EPC GEN2, ISO/IEC 18000-6C
    Reading Range : ~2m (Depending on environment and tag type)
    Writing Range : ~0.5m (Depending on environment and tag type)
    RF Output : 1W / 30dBm (MAX)
    Antenna : Circularly Polarized Antenna (5 dBi)

    Support Frequency (Optional)
    US/FCC : 902.75~927.25 MHz
    EU/CE : 865.7~867.5 MHz
    JP/TELEC : 916.8~920.8 MHz

    USER ENVIRONMENT
    Operating Temperature -10℃ to 50℃
    Storage Temperature -30℃ to 70℃
    Humidity 5~95% (non – condensing)

    ▪ Some features are optional and must be selected upon purchase.
    ▪ All Features and specifications described are subject to change without notice.

    Accessories

    USB Cable USB Cable
    ATT739 Dedicated USB Cable
    Slotted Screwdriver Screwdriver
    Slotted Screwdriver

    Downloads

    Manual

    SDK
